Difference Tape
Used for securing display panels and bonding materials within PCBs (Printed Circuit Boards).
Features
Offers a range of adhesive strengths, leaves no residue after use, and has excellent reworkability.
| GRADE NO. | STRUCTURE | MATERIALS | HEAT RESISTANCE (°C/MIN) |
ADHESION (gf/in) |
COLOR | THICKNESS(㎛) | |
|---|---|---|---|---|---|---|---|
| BASE FILM(㎛) | TOTAL(㎛) | ||||||
| CDT-SA2550 |
FLUORO LINER SILICONE PET ACRYLIC SILICONE RELEASE LINER |
PET | 150/30 | SI: 100 AC: 2000 |
TRANSPARENT | 25 | 80 |
| CDT-SA2570FC |
FLUORO LINER SILICONE PET ACRYLIC SILICONE RELEASE LINER |
PET | 150/30 | SI: 1000 AC: 2000 |
TRANSPARENT | 25 | 100 |
※ Internal specifications can be modified upon user’s demand
Conductive Tape
Used for securing metal-to-metal joints where both conductivity
and adhesion are required, utilizing conductive adhesive.
Features
Conductive adhesive tape without any backing material.
Favorable for product weight reduction.
| GRADE NO. | STRUCTURE | MATERIALS | HEAT RESISTANCE (°C/MIN) |
ADHESION (gf/in) |
COLOR | THICKNESS(㎛) | |
|---|---|---|---|---|---|---|---|
| BASE FILM(㎛) | TOTAL(㎛) | ||||||
| CDT-20DL-C |
SILICONE RELEASE LINER ACRYLIC SILICONE RELEASE LINER |
PET | 100/30 | 1000 | TRANSPARENT | - | 20 |
※ Internal specifications can be modified upon user’s demand
