Using silicone adhesives, we secure stable physical properties in processes requiring chemical and high temperature tape.
Our products are used in various ways including process protection, shipment protection, (Flexible) Printed Circuit Board (PCB) masking, AL protection, Plating, and fabric seams
Product Features
Superior chemical and high temperature tape
Excellent wettability
No residue upon peeling
Single-sided HCT-965
Single-sided HCT-965
Single-sided HCT-933
Single-sided MA120
Single-sided KC-2525
Single-sided HCT-501DG
Single-sided HCT-S5001
Double-sided HCT- DS2564G
Double-sided HCT-965DS
METAL HCT-153
| GRADE NO. | STRUCTURE | MATERIALS | HEAT RESISTANCE (°C/MIN) |
ADHESION (gf/in) |
COLOR | THICKNESS(㎛) | |
|---|---|---|---|---|---|---|---|
| BASE FILM(㎛) | TOTAL(㎛) | ||||||
| HCT-940 |
PET SILICONE |
PET | 150/30 | 450 | BROWN | 25 | 40 |
| HCT-950A |
PET SILICONE |
PET | 150/30 | 350 | GREEN | 25 | 50 |
| HCT-965 |
PET SILICONE |
PET | 150/30 | 800 | GREEN, RED, BLUE | 25 | 65 |
| HCT-933 |
PET SILICONE |
PET | 150/30 | 900 | GREEN, RED, YELLOW, TRANSPARENT | 25 | 80 |
| HCT-300S |
PET SILICONE |
PET | 150/20 | 120 | TRANSPARENT | 19 | 30 |
| MA120 |
PET SILICONE |
PET | 150/30 | 120 | TRANSPARENT | 25 | 40 |
| KC-2525 |
PET SILICONE |
PET | 150/30 | 250 | TRANSPARENT | 25 | 35 |
| HCT-3865 |
PET SILICONE |
PET | 150/30 | 650 | RED | 38 | 65 |
| HCT-3890 |
PET SILICONE |
PET | 150/30 | 850 | BLUE | 38 | 90 |
| HCT-501DG |
PET SILICONE |
PET | 150/30 | 1000 | DARK GREEN | 50 | 90 |
| HCT-S5001 |
PET SILICONE |
PET | 150/30 | 110 | TRANSPARENT | 50 | 55 |
| PET250g |
PET SILICONE |
PET | 150/30 | 250 | TRANSPARENT | 50 | 60 |
| HCT-753 |
PET SILICONE |
PET | 150/30 | 7 | TRANSPARENT | 75 | 90 |
| HCT-S100 |
PET SILICONE |
PET | 150/30 | 4 | TRANSPARENT | 100 | 110 |
| HCT-S250L |
PET SILICONE LINER |
PET | 150/30 | 10 | TRANSPARENT | 50/25(liner) | 55 |
| GRADE NO. | STRUCTURE | MATERIALS | HEAT RESISTANCE (°C/MIN) |
ADHESION (gf/in) |
COLOR | THICKNESS(㎛) | |
|---|---|---|---|---|---|---|---|
| BASE FILM(㎛) | TOTAL(㎛) | ||||||
| HCT- DS2564G |
SILICONE PET SILICONE FLUORO LINER |
PET | 200/120 | TOP: 100 BOTTOM: 400 |
GREEN | 25 | 119 |
| HCT-965DS |
SILICONE PET SILICONE FLUORO LINER |
PET | 200/120 | TOP: 800 BOTTOM: 800 |
GREEN | 25 | 105 |
| GRADE NO. | STRUCTURE | MATERIALS | HEAT RESISTANCE (°C/MIN) |
ADHESION (gf/in) |
COLOR | THICKNESS(㎛) | |
|---|---|---|---|---|---|---|---|
| BASE FILM(㎛) | TOTAL(㎛) | ||||||
| HCT- 153DR |
PET SILICONE |
PET | 150/30 | 250 | RED | 38 | 51 |
| HCT- 153DO |
PET SILICONE |
PET | 150/30 | 250 | ORANGE | 38 | 51 |
| HCT- 153DG |
PET SILICONE |
PET | 150/30 | 250 | GREEN | 38 | 51 |
| HCT- 153DB |
PET SILICONE |
PET | 150/30 | 250 | BROWN | 38 | 51 |
| HCT-950DF |
PET SILICONE |
PET | 150/30 | 250 | BLUE | 38 | 51 |
※ Internal specifications can be modified upon user’s demand
